Description
Benefits
Projection Technology
Texas Instruments DLP®
Panel Size
0.47" DMD
Native Resolution
4K UHD
Pixels
3840 x 2160
Aspect Ratio
16:9
Contrast Ratio
1000000:1
Brightness (ISO Lumens)
4000
Light Source
UHP Lamp
Light Source Life Maximum Hours
15000
Maximum Supported Resolution
3840 x 2160
Horizontal Sync. Range (KHz)
15 ~ 150
Vertical Sync. Range (Hz)
24 ~ 240
Uniformity (%)
80
Lens
1.3x
Lens Zoom Adjustment
Manual
Optional Lenses
-
Image Offset (%)
115
Focal Length (mm)
12.81 ~ 16.74
F-Stop
2.43
Vertical Lens shift (%)
-
Horizontal Lens shift (%)
-
Keystone Adjustment
Manual/Automatic
Vertical Keystone Correction
± 30°
Horizontal Keystone Correction
± 30°
Projection Factor
1.21 ~ 2.59:1
Projection Distance (Meters/Feet)
1.0 ~ 8.1 / 3.2 ~ 26.6
Optical Zoom
1.3:1
Digital Zoom Demagnification / Magnification
0.8x ~ 2.0x
Focus Adjustment
Manual
Inputs
2x HDMI™ 2.0 (HDCP 2.2), Mini D-sub 15-pin (VGA), 3.5 mm Stereo Mini Jack
Outputs
3.5 mm Stereo Mini Jack, USB-A Power 5v 1.5A, S/PDIF Optical Audio
Networking & Control
RS232
Embedded System
-
3D
Full 3D All Major Formats
Power Supply
100 ~ 240 V AC; 50 ~ 60 Hz
Power Consumption Max (W)
300
Power Consumption Min (W)
210
Power Consumption Network Standby (W)
-
Power Consumption Standby (W)
<0.5
Product Dimensions (L x W x H) (mm / in)
313 x 234 x 96.4 / 12.4 x 9.2 x 3.8
Product Weight (Kilograms/Pounds)
3.2/7.0
Packaged Dimensions (L x W x H) (mm / in)
400 x 337 x 168 / 15.7 x 13.3 x 6.6
Packaged Weight (Kilograms/Pounds)
4.4 / 9.7
Fan Noise (dB)
27
Audio (W)
1 x 10
Operating Temperature (Celsius/Fahrenheit)
0 ~ 40 / 32 ~ 104
Operating Humidity (%)
10 ~ 80
Max Operating Altitude (meters / feet)
3048 / 10000
Storage Temperature (Celsius/Fahrenheit)
-20 ~ 60 / -4 ~ 140
Storage Humidity (%) Non-condensing
10 ~ 80
Security
Kensington Security Slot™, PIN Code Lock & Timer
Safety and Regulatory
CB, CE, EAC, cTUVus, CCC, FCC, UKCA
Environmental
WEEE, EU RoHS, China RoHS
